22kw EV Charging Station to Match Plug EV Charging Connector Type 2 to Type 2

Basic Info

Model NO.	AG-E5T2432
Current	16A Single Phase
Power	22kw
Customization	Yes
Technical Exchange	Face to Face
Service	OEM & ODM
Project	Pre-Evaluation with Client
Delivery	Fast and Efficiency
Transport Package	by Sea, by Air
Specification	400*280*150mm
Trademark	AEGEN
Origin	Zhejiang
HS Code	8504409999
Production Capacity	3000sets/Month

Product Description

TYPE 2 10A-32A 1-Phase - 3Phase3.7KW -7.4 KW -22KW Capacity
Product Specification
Mode: A Certificate: CE
Current: 10A-32A 1-Phase - 3Phase
Power: 3.7KW -7.4 KW -22KW
Size: 327*200*132mm

Key Features
-High compatibility. It can charge all EVs manufactured in Europe correctly and effectively.
-Easy to install. Products are sent to clients with associated installation tools and users manual .Users are able to install the charger .
-Easy to maintain. The modularized structure makes easy maintenance ,once anywhere was wrong ,just replace one part like controller / contactor / type B RCD

Technical data sheet
Compliance	IEC 61851
Certificate	CB by Bureau Veritas,CE,Rohs
Current	16A 32A
Power	3.7KW 7.2KW 11KW 22KW
Key parts	Type B RCD
Branding	Branding clients' logo on ev charger and inside key parts to make a whole series
Packing size	40*40*26.5cm
Weight	G.W./N.W. 6.6kg/5.5kg
Rated Supply Voltage	1-phase 230V±20% 3-phase 400V±20%
Rated Operating Frequency	50HZ/60HZ
Charging Control Pattern	RFID access control (optional)
Options	Cable version | Socket version | Cable version with RCMU| Socket version with RCMU|
	Cable version with Dynamic Load Balance |Socket version with Dynamic Load Balance |
	Cable version with RFID | Socket verion with RFID
Protection Level	IP55
Sockets/Plugs	Type 2 Type 1
Cable Length	5m
